The XC137 is a screw-type terminal block primarily used for:
Electrical Connections: Connecting wires to transmit current or electrical signals. It is widely used in electronic equipment, circuit boards, switches, sockets, and other devices.
Features:
1.Stability: The screw securely connects wires to circuit boards or other electrical components, ensuring a reliable connection.
2.Adaptability: Capable of connecting wires of different diameters. Its simple and effective design makes it easy to install and maintain.
3.Wide Applications: Commonly used in distribution boxes, controllers, automotive electrical systems, and other applications.
These features make screw-type terminal blocks an essential component for electrical connections.
| UL/CUL Techical Date | |||
| Use Grroup | B | C | D |
| Rated Voltage(V) | 600 | . | 300 |
| Rated Current(A) | 125 | . | 10 |
| Wire Range Solid/Stranded(AWG) |
20-2 | ||
| Withstanding VOLTAGE | 2200V/Min | ||
| IEC Techical Date | |||
| Overvoltage Category | Ⅲ | Ⅲ | Ⅱ |
| Contamination Class | 3 | 2 | 2 |
| Rated Voltage(V) | 1000 | 1000 | 1000 |
| Rated Current(A) | 115 | 115 | 115 |
| Impulse Withstand Voltagea(KV) | 8.0 | 8.0 | 8.0 |
| Conductor cross section Solid/Flexible(mm³) |
35.0 | ||
| Material | |||
| Lnsulation Material | PA66 | ||
| Lmflammability | UL94V-0 | ||
| Contactor Material | Copper alloy | ||
| Contactive Coating | Tin plated | ||
| Mechanical | |||
| Pitch (mm) | 15.00 | ||
| Poles (p) | 2-12 | ||
| Stripping Length(mm) | 18 | ||
| Screw/Torque(Max)(N.M) | M5.0/2.0 | ||
| Operating temperatur(℃) | -40-+105 | ||
| Pin Dimensions | 4.5 | ||
| PCB Hole Diameter(mm) | 2.0 | ||
