XC15EDGRKM-3.81mm
Pluggable terminal blocks are best-sellers both domestically and internationally. The sockets of these terminal blocks can be equipped with mounting clips or locking clips. Mounting clips provide more secure fixation to the PCB, while locking clips lock the connector and socket in place after installation. Various socket designs are available to accommodate different insertion methods of the connector, including horizontal, vertical, or angled insertion into the PCB. Both metric and standard wire gauges are available.
For more information on the applications of pluggable terminal blocks, please contact us. Our professional staff will be happy to assist you.
| UL/CUL Techical Date | |||
| Use Grroup | B | C | D |
| Rated Voltage(V) | 300 | . | 300 |
| Rated Current(A) | 8 | . | 10 |
| Wire Range Solid/Stranded(AWG) |
28-16 | ||
| Withstanding VOLTAGE | 1600V/Min | ||
| IEC Techical Date | |||
| Overvoltage Category | Ⅲ | Ⅲ | Ⅱ |
| Contamination Class | 3 | 2 | 2 |
| Rated Voltage(V) | . | 160 | 320 |
| Rated Current(A) | . | 7 | 7 |
| Impulse Withstand Voltagea(KV) | . | 2.5 | 2.5 |
| Conductor cross section Solid/Flexible(mm³) |
1.5 | ||
| Material | |||
| Lnsulation Material | PA66 | ||
| Lmflammability | UL94V-0 | ||
| Contactor Material | Copper alloy | ||
| Contactive Coating | Tin plated | ||
| Mechanical | |||
| Pitch (mm) | 3.81 | ||
| Poles (p) | 2-24 | ||
| Stripping Length(mm) | 7-8 | ||
| Screw/Torque(Max)(N.M) | M2.0/0.2 | ||
| Operating temperatur(℃) | -40-+105 | ||
| Pin Dimensions | . | ||
| PCB Hole Diameter(mm) | . | ||
